- Place of Origin: nanjing
- Brand Name: JINHUIRACKING
- Model Number: PR
Product Name:factory wholesale industrial racking
Introduction:
Most widely used as one of storage system,pallet has the feature of good appearance,safety, fast in picking and storage room saving.Painting is fast and lasts as the surface is painted by spraying static power.Each level can be adjustable at 75mm per pitch and the maximum length of 16 meters.
This type of rack is suitable for storage of all kinds of goods with the feature of fast in picking and withdrawing,suitable for operation by fortlift.
- Place of Origin: nanjing
- Brand Name: JINHUIRACKING
- Model Number: PR
Detail about Heavy Duty Racking:
Type | Heavy duty racking |
Merterial | Column is C-steel;Beam is P-beam;Laminate is cold-rolled steel plate; |
Logo | JINHUI |
Color | Any color is available |
Effect | Warehouse,Factory |
Use | Material flow,electrical mechanic, aviation,electronics,machinery,automobile,post, railway,food,petrification,supermarket,finance and so on. |
MOQ | 10pcs,small quantity and mix order are welcome |
Size | Length:0.5*2.5m,0.6-2.5m.High:2-16m. |
Surface treament | Polyester baking finish and epoxy resin powder electostatic process. Coating thickness:45-110 micron. |
Place of origin | NANJING,China |
Sampling | 5-7 days |
Packing | Packing term: Foam and cardboard Separated packing method : Upright frame, beam , support board separated in box. |
Port | Shenzhen,guangzhou,china |
Payment | L/C,T/T,Westerm Union,Paypal,cash |
Material | Upright:90*70mm,Beam:120*45mm |
Daily output | 5sets/day/set mould. |
Warranty time | Long warranty time for 3 years,shelf working life for 20 years; |
Advantages | 1.This storage shelf, ideal for loading molds that require secure storage with easy access, can be installed freely and have good load capacity, competitive price. 2.Cut-in composite beam structure, the height of each layer can be adjusted freely for convenient storage. 3.Connection of main and subsidiary frames for saving space and costs. It can be used single or connected one by one freely. 4.This shelf ensures the efficient storage of a wide range of goods. 5.Various styles, thickness, colors and sizes can make |
Performance of Racking System | Bulk Storage | Selective Pallet Rack |
Selectivity of individual pallets | 40% | 100% |
Use of floor space | 80% | 50% |
Utilization of pallet posting | 70% | 98% |
Speed of access and throughput | 80% | 80% |
Stock rotation (FIFO) | 40% | 60% |
Use of building height | 30% | 80% |
Efficient Bottom Level Case Picker | No | Yes |
Ease of relocation | 100% | 100% |
System adjustability | 100% | 100% |
Specialist handling equipment | No | No |
Features:
1>The simplest, lowest cost, most popular racking system in the world.
2> Convenience to stock management.
3> Easy to store and pick due to direct access to all pallets.
4>Compatible with many handling equipment styles.
5>The height between levels can be adjusted easily by 50/70/76.2mm pitch interval.
6> Lower level pallets can be located on the floor for picking purposes.
7>Ideal for warehouses, which need to keep a wide variety of products.
8> Fully compatible with Dexion racking system, allowing you replace parts or add new bay based on the existing racking system.
9> Disadvantage: Low efficiency for utilization of space, storeage density is low with only 35% floor space and only 25% cubic space used.
